MODEL：ECD650-E
Active Surface Area(m2)：0.135
Design Flow (m³/hr)：0.08
Membrane Thickness(mm)：2
Bubble Size(mm)：1-2
Hole Size：1mm or 2mm
Slit Quantity：10000
SOTE（%）（4.5m Watet Depth)：28-36
Drag Loss(Pa)：1286-2604
Service Life(year)：≥5
SSI's ECD650 comes in several membrane materials including our patented PTFE membrane, designed to use less energy and require minimal maintenance. Piping and less air£ low needed to operate the ECD650 panel diffuser, equivalent in size to four of our 9" AFD270 discs.
MODEL型号 | ECD650-E |
Active Surface Area(m2) 有效面积 | 0.135 |
Design Flow (m³/hr) 设计风量 | 0.08 |
Membrane Thickness(mm) 膜片厚度 | 2 |
Bubble Size(mm)气泡直径 | 1-2 |
Hole Size孔缝尺寸（mm) | 1mm or 2mm |
Slit Quantity 膜片打孔数量 | 10000 |
SOTE（%）氧利用率 （4.5m Watet Depth) | 28-36 |
Drag Loss(Pa) | 1286-2604 |
Service Life(year)寿命 | ≥5 |
